John Deere 317 Price, Specs, Review & Attachments 2022
Matthew Wilson John Deere 317 Price, Specs, Review, Horsepower, Attachments, Weight, Engine Oil Capacity & Pictures
John Deere 317 Garden Tractor is equipped with a Kolher KT17QS gasoline 2-cylinder air-cooled horizontal-shaft, 691 cc engine, which produces 17 hp power at rated rpm 3600.
The early versions suffered from insufficient lubrication of the connecting rod journals when run on hillsides.
An improved KT17 Series II engine was used beginning with engine specification number 24300 in 1982.
John Deere 317 Garden tractor is capable of using plows, tillers, or other ground-engaging attachments.
Now, let’s find out the John Deere 317 Garden Tractor Price, Specs, Review, Attachments, Weight, Features & Images, and more. I hope it will be useful to you.
John Deere 317 Price
Original Price: $2,000.00 USD
John Deere 317 Serial Numbers
| 1979 | 95001 |
| 1980 | 120001 |
| 1981 | 155001 |
| 1982 | 190001 |
| 1983 | 222001 |
| Final | 285000 |
John Deere 317 Review Video
John Deere 317 Specs
John Deere 317 ENGINE
| Engine | Kohler KT17QS gasoline 2-cylinder air-cooled horizontal-shaft |
| Displacement | 691 cc 42.18 ci |
| Bore/Stroke | 3.125×2.750 inches 79 x 70 mm |
| Power | 17 hp 12.7 kW |
| Rated RPM | 3600 |
| Starter volts | 12 |
| Oil Capacity | 1.5 qts 1.4 L |
John Deere 317 TRANSMISSION
| Transmission | Sundstrand Series 15 Model 90 |
| Type | hydrostatic |
| Gears | infinite forward and reverse |
| Oil Capacity | 5 qts 4.7 L |
John Deere 317 TIRES
| Lawn/turf front | 16×6.50-8 |
| Lawn/turf rear | 23×10.50-12 |
John Deere 317 PTO
| Front PTO | independent |
| Clutch | electric |
John Deere 317 MECHANICAL
| Chassis | 4×2 2WD |
| Steering | manual |
| Brakes | differential mechanical shoe |
| Cab | Open operator station. |
John Deere 317 DIMENSIONS
| Wheelbase | 46 inches 116 cm |
| Length | 69 inches 175 cm |
| Width | 42.5 inches 107 cm |
| Height | 44 inches 111 cm |
| Weight | 700 lbs 317 kg |
John Deere 317 ELECTRICAL
| Ground | negative |
| Battery volts | 12 |
John Deere 317 Attachments
| 46″ mid-mount mower deck | |
| 48″ mid-mount mower deck | |
| 50″ mid-mount mower deck |
Final Words
That’s all about the John Deere 317 Tractor Price, Specification, Review, Attachments, and Features. But If you have any problem regarding this post, then please comment in the below comment box. I will try to solve your problem as soon as possible. Thanks.
